INT SQ END PLATE - STD OVAL TURN AND LEVER 41 SATIN CHROME

Lockwood 4600 Series Narrow Stile Plate Furniture

A slim-line, rectangular brass plate that adds style to your choice of lever.

With a pitch specifically designed for use with the Lockwood 3570 Series Mortice Latches

The Lockwood Brass Door Furniture range is the culmination of decades of experience in the design and manufacture of high quality door furniture. Over the years the Lockwood brass door range has evolved as the product of choice for leading architects in commercial, institutional and industrial applications.

Features

• Lockwood lever 41 Intermezzo
• Internal plate with visible fixing (screws not included)
• Standard oval turn
• Left handed
• Supplied in trade pack

Plate Dimensions
Height: 185mm
Width: 26mm
Depth: 11.5mm
Pitch: 64mm
Fixing centres: 160mm

Lever Dimensions
Length: 130mm
Projection: 61.5mm
Finger clearance: 40.5mm

When using plate configurations that feature turns a unique mechanism is employed that automatically adjusts the length of the tail bar to suit a particular door thickness.

Handing
Levers of asymmetrical design cannot be reversed. Specify left or right handed when ordering.

Fixing
Plates are designed to fit back to back. If outside plate is specified with concealed fixing, then the inside plate must be visible fixed.External plates are supplied with fixing screws to suit door thickness between 32mm and 45mm.

Finish
Available in the Australian range of powdercoat colour s
