PARADIGM PULL HANDLE DOUBLE CYLINDER DEADBOLT STAINLESS STEEL

Lockwood Paradigm 005 Pull Handle Lockset

The Australian designed Paradigm® Pull Handle Lockset expresses superior state-of-the art design featuring a contemporary style that delivers exceptional safety and security. Suitable for residential, new building and renovation market applications. The Pull Handle lockset incorporates innovative safety features from the Paradigm 005 Deadbolt and is manufactured with high end 304 grade stainless steel that comes in a brushed satin finish.

Features:

• Brushed 304 grade stainless steel pull handle
• Concealed screw fixings
• Square rose escutcheon design
• Conforms to the security and durability requirements of Australian Standard AS4145.2-2008 | SL8D8C6K5
• Multi-mode slim-line deadbolt providing safety, security and convenience
• Simple to install
• High security, cut resistant stainless steel bolt
• Box strike with concealed cross-grain doorframe strengthening screw
• Backset is 60mm to 70mm adjustable stainless steel bolt.
• Cylinder is 5 pin tumbler mechanism
• Brass cylinder and brass barrel
• High purity zinc alloy
• Suits door thickness 32mm-48mm. However, 32-36mm doors require spacer ring (included)
• Plated finish
• Supplied in display pack

Dimensions
External handle length - 600mm
Internal handle length - 500mm
Handle width - 30mm

Keying
Standard Keying

• Supplied individually keyed with two keys per lock
• 78,000 key combinations
• Key blank KB2015P
• AS 4145.2-2008 K5

Restricted Special Keying
Lockwood locks can be keyed to a number of controlled and/or specially keyed systems.
These range from legally protected keys to protect against unauthorised duplication, which can also include specially designed key systems such as master key systems, which allow for different levels of mechanical access control.

The Lockwood Paradigm 005 Deadbolt incorporates Lockwoods patented LockAlert status indicator that shows the Lockset mode at a glance. The lockset can operate in three modes:

• Secure Mode - Locked from the inside and outside.
• Safety Mode - Locked from the outside and free to exit from inside.
• Passage Mode - Free to enter from outside and free to exit from inside.

Dual Select®
Turn the key for safety mode. Turn the key further to select secure mode.

Safety Release™
Automatically unlocks the internal knob upon entry minimising the risk of being locked in.

Anti-Corrosion
Successfully tested in accordance with AS2332.3.1:2001 neutral salt spray test.

Kinetic Defence®
Bump and pick resistant.

Counterbalance Bolt
Proportionally distributes the load between the door and door frame.

Retrofitable

• Replace your existing Deadbolt.
• Fits 54mm hole.
• 60-70mm adjustable backset.
• 32-48mm door thickness.

2 Keys Included and can be keyed alike to other Lockwood door locks.

Finish
Satin Stainless Steel SSS
