DETENTION PLATE CONCEALED FIX - STD TURN WITH LEVER 23 LH SELECTOR STAINLESS STEEL

Lockwood Detention Furniture - 220 Series

The Lockwood Detention Furniture 220 Series range was developed after extensive research with government representatives, architects, nurses and locksmiths experienced in correctional, juvenile justice and health departments.

A heavy duty plate designed for use in hospitals and detention facilities, Lockwoods solution protects the well-being of patients and inmates without compromising security and staff safety. Styled for institutional use, this plate has six fixing points to ensure that it is well secured to the door; plates are designed to be free of ligature points. The detention flush pull has been designed to maximise grip and eliminate the possibility of hiding objects in the cavity.

Ergonomically designed to maximise grip, the Lockwood Detention lever is suitable for use in hospitals and minimum security applications. It caters especially for the elderly or people with arthritic conditions.

Application

• Lockwood 3770 Selector Series Mortice Locks

Features

• Lever with standard turn
• Concealed fixing at 6 points
• Anti-ligature design
• Left handed
• Covers fixing holes from existing Artefact 200 Series Furniture
• Suits door thickness 35mm to 45mm (For thicker doors, longer screws are required)
• Cylinders and cylinder guards sold separately
• Detention furniture turns feature a clutching mechanism that allows the cylinder to retract the bolt even if the turn knob is held from the inside
• Manufactured from stainless steel
• Fire rated up to 2 hours
• Supplied in trade pack
• Australian designed

Dimensions
Base Plate
Height: 162mm
Width: 180mm
Thickness: 2mm

Bevelled Top Plate
Height: 161mm
Width: 75mm
thickness: 3mm

Note: A minimum door thickness of 50mm is required to fit flush pulls back to back.

Finish
Satin Stainless Steel
