220D57NA/21LSS
DETENTION PLATE CONCEALED FIX - CYLINDER WITH PULL HANDLE AND KNOB 21 LH STAINLESS STEEL
Avg. Dispatch Time : 29 Day
Price is exclusive of Taxes
Lockwood Detention Furniture - 220 Series
The Lockwood Detention Furniture 220 Series range was developed after extensive research with government representatives, architects, nurses and locksmiths experienced in correctional, juvenile justice and health departments.
A heavy duty plate designed for use in hospitals and detention facilities, Lockwoods solution protects the well-being of patients and inmates without compromising security and staff safety. Styled for institutional use, this plate has six fixing points to ensure that it is well secured to the door; plates are designed to be free of ligature points. The detention flush pull has been designed to maximise grip and eliminate the possibility of hiding objects in the cavity.
Simple yet functional, the Lockwood Detention standard knob has soft edges to minimise impact injuries and antiligature features that make it suitable for use in detention facilities. The Lockwood Detention pull allows for a firm grip and can be used to open heavy doors. Also designed to be free of hanging points.
Application
Features
Dimensions
Base Plate
Height: 162mm
Width: 180mm
Thickness: 2mm
Bevelled Top Plate
Height: 161mm
Width: 75mm
thickness: 3mm
Note: A minimum door thickness of 50mm is required to fit flush pulls back to back.
Finish
Satin Stainless Steel
The Lockwood Detention Furniture 220 Series range was developed after extensive research with government representatives, architects, nurses and locksmiths experienced in correctional, juvenile justice and health departments.
A heavy duty plate designed for use in hospitals and detention facilities, Lockwoods solution protects the well-being of patients and inmates without compromising security and staff safety. Styled for institutional use, this plate has six fixing points to ensure that it is well secured to the door; plates are designed to be free of ligature points. The detention flush pull has been designed to maximise grip and eliminate the possibility of hiding objects in the cavity.
Simple yet functional, the Lockwood Detention standard knob has soft edges to minimise impact injuries and antiligature features that make it suitable for use in detention facilities. The Lockwood Detention pull allows for a firm grip and can be used to open heavy doors. Also designed to be free of hanging points.
Application
- Lockwood 3770 Selector Series Mortice Locks
- Lockwood 3570 Synergy Series Mortice Locks
- Lockwood 3579 Synergy Secure Area Rated Locks
Features
- Standard knob and pull handle with cylinder hole
- Concealed fixing at 6 points
- Anti-ligature design
- Left handed
- Covers fixing holes from existing Artefact 200 Series Furniture
- Suits door thickness 35mm to 45mm (For thicker doors, longer screws are required)
- Cylinders and cylinder guards sold separately
- Detention furniture turns feature a clutching mechanism that allows the cylinder to retract the bolt even if the turn knob is held from the inside
- Manufactured from stainless steel
- Fire rated up to 2 hours
- Supplied in trade pack
- Australian designed
Dimensions
Base Plate
Height: 162mm
Width: 180mm
Thickness: 2mm
Bevelled Top Plate
Height: 161mm
Width: 75mm
thickness: 3mm
Note: A minimum door thickness of 50mm is required to fit flush pulls back to back.
Finish
Satin Stainless Steel
| Model No | 220D57NA/21LSS |
|---|---|
| EAN | 9340116005706 |
| Fire Rating | up to 2 hours |
| Compatible with Restricted Keying | Yes |
| Handing | Left |
| Cylinder Type | 570 |
| Rose Design | Square |
| Handle Escutcheon | On Plate |
| Packing Type | Box |
| Door Type | Hinged |
| Tested to Standards | Tested to Australian Standard |
| Residential | No |
| Fixing Type | Concealed |
| Door Thickness Range | 35mm-45mm |
| Case material for exterior | Stainless Steel |
| Fixing Method | Back to Back |
| LED indicator | No |
| Rekeyable | Yes |
