21305NN/96SS
213 INTERIOR PLATE & 96 LEVER STAINLESS STEEL
Avg. Dispatch Time : 22 Day
Price is exclusive of Taxes
Lockwood 212 Series Artefact Oval Plate Door Furniture
The distinguished range of Artefact in Aluminium, Brass and Stainless Steel, offers architects and specifiers a complete range of slim line, door furniture plates.
Suitable for use in public, commercial, industrial and institutional buildings, where there is a need for high grade and durable fittings. Artefact range of door furniture plates offers a selection of functions with engraving available to suit most requirements.
The 212 Series Door Furniture is 162mm long x 50mm wide with radius ends. Concealed fixed plates have studs with internal threads located top and bottom, visible fixed plates have corresponding countersunk holes and are fixed back to back through the door.
Application
Designed for use with Lockwood Synergy 3570 and Selector 3770 Series Mortice Locks; Latches and Push and Pull doors
Features
Plate Dimensions
Plate dimensions: 50mm x 162mm x 2mm
Cylinder pitch: 64mm
Materials
Aluminium / Brass / Stainless Steel
Door Thickness
35 to 45mm standard. For doors 45 to 55mm thick, specify long fixing screws SP2000-208.
When using flush pulls back to back the minimum door thickness is 40mm.
Finish
Satin Stainless Steel SS
The distinguished range of Artefact in Aluminium, Brass and Stainless Steel, offers architects and specifiers a complete range of slim line, door furniture plates.
Suitable for use in public, commercial, industrial and institutional buildings, where there is a need for high grade and durable fittings. Artefact range of door furniture plates offers a selection of functions with engraving available to suit most requirements.
The 212 Series Door Furniture is 162mm long x 50mm wide with radius ends. Concealed fixed plates have studs with internal threads located top and bottom, visible fixed plates have corresponding countersunk holes and are fixed back to back through the door.
Application
Designed for use with Lockwood Synergy 3570 and Selector 3770 Series Mortice Locks; Latches and Push and Pull doors
Features
- External plate with 96 lever
- Visible fixings (screws not included)
- No Cylinder or turn snib
- Non-handed
- Fire rated up to 2 hours
- Supplied in trade pack
Plate Dimensions
Plate dimensions: 50mm x 162mm x 2mm
Cylinder pitch: 64mm
Materials
Aluminium / Brass / Stainless Steel
Door Thickness
35 to 45mm standard. For doors 45 to 55mm thick, specify long fixing screws SP2000-208.
When using flush pulls back to back the minimum door thickness is 40mm.
Finish
Satin Stainless Steel SS
| Model No | 21305NN/96SS |
|---|---|
| EAN | 9311847905450 |
| Tested to Standards | Tested to NZ Standard |
| Door Thickness Range | MIN 35mm |
